Shanghai NuoSai Pump Manufacturing Co., Ltd.
Model No.: NSLA
Name: Inline Water Circulation Pump
| Selling Units | : | Set/Sets |
Product Description of Single Stage Vertical Pipeline Circulating Pump
Single Stage Vertical Pipeline Circulating Pump with pump inlet and outlet in the same straight line at the bottom of the pump. The product is designed in the form of disassembly and assembly that can be pulled out at the top. The pump can be repaired without affecting the piping system
FEATURES AND ADVANTAGES
Compact structure and convenient maintenance. Low noise.
Optional cast iron or stainless steel impeller.
NSLA Technical Parameter Vertical Inline Single Stage Centrifugal Water Circulation Pump
1，Flow：2-2000m³/h
2, Head：Max 140m
3，Power：Max 200kW
4，Working Pressure：16bar and 25bar
5，Rated Voltage/Frequency：380V/50Hz
6，Motor Protection level：IP54/IP55
7，Media Condition：Solid Partical≤200mg/L , chemical properties,Which are similar to water.
8，Media Temperature：-20℃~+120℃
9, Enviroment Temperature：max ≤+40℃
Motor:
Protection grade:IP55
Insulation grade:F
Voltage:50HZ
Working Mode:S1
Model of Vertical Inline Single Stage Centrifugal Water Circulation Pump
